Nevatia Steel wires are also used for further redrawing into finer wires.
Characteristics of Redraw Wire
- Clean, matte surface
- Soft wire suitable for drawing into fine diameters
- High coil weights in drums or on carriers for minimum change-over
AISI 302, 304, 304L, 316, 316L, 316Ti, 314, 321, 430L, 434A etc.
|Diameter (mm)||Grade (AISI)||Tolerance (mm)||Tensile (N/mm²)||Packing|
|0.60 - 2.00||300 series||+/- 0.015||650 - 800||Coils/ Pay-pack Drums|
|2.01 & above||+/- 0.020||600 - 750||Coils/ Pattern laid coils|
|0.60 - 2.00||400 series||+/- 0.015||500 - 650||Coils/ Pay-pack Drums|
|2.01 & above||+/- 0.020||450 - 600||Coils/ Pattern laid coils|
|Please check with us for specifications not listed above|
