Braiding, Knitting & Weaving

Braiding, Knitting & Weaving Quality

Wire suitable for Braiding, Knitting & Weaving applications mainly used in mesh manufacturing, automotive, printing and filter Industries.

Characteristics of Weaving Wire

  • Shiny surface condition
  • Controlled mechanical properties w.r.t. individual application
  • High resistance to corrosion

Grades

AISI 304 /(L), 316/ (L), 316 Ti, 310, 314, 321, etc.

Specifications

Diameter (mm)Tolerance (mm)Tensile (N/mm²)Packaging and Spool type
0.100 - 0.250+/- 0.004850 maxDIN 125/ 160/ 200/ US200 (NS10) / NS5
0.260 - 0.400+/- 0.005830 maxDIN 200/ 250/ US200 (NS10)/ US 250 / PT15 / PT25
0.410 - 0.630+/- 0.007800 maxDIN 250/ US250/ DIN355
0.635 - 0.800+/- 0.009780 maxDIN 355/ Pay-pack Drums/ Coils

Please check with us for specification not list above.

Spools

Diameter (mm)Spools Spool Wt. (Kg)Wire Wt. Max (kgs)Spool Dimensions (mm)
D1D2D3L1L2
0.100 - 0.200DIN 1250.153.001258016100125
0.100 - 0.250DIN 1600.356.5016010022128160
0.150 - 0.400DIN 2000.7014.0020012522160200
0.250 - 0.630DIN 2501.0022.0025016022160200
0.410 - 0.800DIN 3552.0045.0035522436160200
0.150 - 0.400NS10/ US2000.7014.0020011532152187
0.250 - 0.630US 2501.0022.0025016032160200
0.20-0.35PT-150.6415180/20095/10830200227
0.25-0.70PT-251.0525210/225108/12832248278
0.15-0.30NS-50.2251205416130150

Please check with us for specification not list above.
